Antenna Ubiquiti nbe-m5-16 5ghz nanobeam m5 airmax 15om-10km g12

NBE-M5-16
Dimensions 140 x 140 x 54 mm (5.51 x 5.51 x 2.13")
Weight 0.320 kg (0.71 lb)
Power Supply 24V, 0.5A Gigabit PoE
Max. Power Consumption 6W
Operating Frequency Worldwide - 5150 - 5875 MHz
USA: U-NII-1 - 5150 - 5250 MHz
USA: U-NII-2A - 5250 - 5350 MHz
USA: U-NII-2C - 5470 - 5725 MHz
USA: U-NII-3 - 5725 - 5850 MHz
Gain 16 dBi
Networking Interface (1) 10/100/1000 Ethernet Port
Processor Specs Atheros MIPS 74Kc, 533 MHz
Memory 64 MB DDR2, 8 MB Flash
LEDs (1) Power, (1) LAN, (4) WLAN
Signal Strength LEDs Software-Adjustable to Correspond to Custom RSSI Levels
Max. VSWR 1.5:1
Channel Sizes 5/8/10/20/30/40 MHz
Polarization Dual Linear
Enclosure Outdoor UV Stabilized Plastic
Mounting Pole-Mount (Kit Included), Wall-Mount
Wind Loading 21.4 N @ 200 km/h (4.8 lbf @ 125 mph)
Wind Survivability 200 km/h (125 mph)
ESD/EMP Protection Air: ± 24 kV, Contact: ± 24 kV
Operating Temperature -40 to 70° C (-40 to 158° F)
Operating Humidity 5 to 95% Noncondensing
Wireless Approvals FCC, IC, CE
RoHS Compliance Yes
Salt Fog Test IEC 68-2-11 (ASTM B117), Equivalent: MIL-STD-810 G Method 509.5
Vibration Test IEC 68-2-6
Temperature Shock Test IEC 68-2-14
UV Test IEC 68-2-5 at 40° C (104° F), Equivalent: ETS 300 019-1-4
Wind-Driven Rain Test ETS 300 019-1-4, Equivalent: MIL-STD-810 G Method 506.5
